Valves |
|
Type
|
WP
(mpa) |
DN (mm) |
Medium |
Outlet thread |
Inlet thread |
Safety device |
|
QF-15 |
3 |
Φ 4 |
C2H2 |
Φ 21Clamp |
GB8335
PZ39 |
100±5
℃ |
|
QF-15A |
3 |
Φ 4 |
C2H2 |
GB7307
G1/2-14-RH-EXT |
GB8335
PZ39 |
100±5
℃ |
|
CGA510-1 |
3 |
Φ 3 |
C2H2 |
CGA NO.510
.885-14NGO-LH-INT |
ANSI B2.1
3/4-14NPT |
100±5
℃ |
|
CGA200 |
3 |
Φ 3 |
C2H2 |
CGA NO.510
.885-14NGO-LH-INT |
CGA
3/8-18NGT |
100±5
℃ |
|
PF5-1 |
3 |
Φ 4 |
C2H2 |
GB7307
G5/8-14-LH-INT |
GB8335
PZ39 |
|
|
YF-4 |
3 |
Φ 4 |
C2H2 |
GB7307
G5/8-14-LH-INT |
GB8335
PZ27.8 |
|
6061 seamless aluminum gas cylinders and liners,
aluminum lined carbon fiber full-wrapped
composite cylinders for breathing apparatus,
aluminum carbon fiber full-wrapped composite
cylinders (CNG type 3 cylinders) for vehicles,
aluminum oxygen therapies, aluminum full-wrapped
composite cylinders for breathing apparatus
|
Specifications Model |
Volume
Lts/Cu ft |
Diameter
（mm/in)
|
Overall Length
（mm/in) |
Thickness（mm) |
Empty Weight
（Kg) |
Service Pressures（MPA) |
|
LWH51-0.15-15 |
0.2 |
51 |
135 |
|
0.2 |
15 |
|
LWH51-0.3-15 |
0.3 |
51 |
238 |
|
0.35 |
15 |
|
LWH63-0.5-15 |
0.5 |
63 |
237 |
|
0.48 |
15 |
|
LWH89-0.5-15 |
0.5 |
89 |
167 |
4.5 |
0.8 |
15 |
|
LWH60-0.6-15 |
0.6 |
60 |
332 |
4 |
0.8 |
15 |
|
LWH75-0.7-17 |
0.7 |
75 |
295 |
4.1 |
0.85 |
15 |
|
LWH81-0.7-15 |
0.7 |
81 |
199 |
|
0.68 |
15 |
|
LWH82-0.7-15 |
0.7 |
82 |
235 |
4.2 |
0.9 |
15 |
|
LWH89-0.7-15 |
0.7 |
89 |
207 |
4.5 |
1 |
15 |
|
LWH108-0.7-15 |
0.7 |
108 |
169 |
5.5 |
1.1 |
15 |
|
LWH81-0.8-15 |
0.8 |
81 |
238 |
|
0.76 |
15 |
|
LWH90-0.8-20 |
0.8 |
90 |
225 |
|
1.2 |
20 |
|
LWH89-1.0-15 |
1.0 |
89 |
269 |
4.5 |
1.2 |
15 |
|
LWH108-1.0-15 |
1.0 |
108 |
210 |
5.5 |
1.3 |
15 |
|
LWH89-1.4-15 |
1.4 |
89 |
345 |
4.5 |
1.4 |
15 |
|
LWH108-1.4-15 |
1.4 |
108 |
264 |
5.5 |
1.6 |
15 |
|
LWH111-1.4-15 |
1.4 |
111 |
235 |
|
1.6 |
15 |
|
LWH111-1.5-15 |
1.5 |
111 |
253 |
|
1.7 |
15 |
|
LWH111-1.9-20 |
1.9 |
111 |
332 |
|
2.7 |
20 |
|
LWH102-2.0-20 |
2.0 |
102 |
390 |
|
2.7 |
20 |
|
LWH108-2.0-15 |
2.0 |
108 |
346 |
5.5 |
2.1 |
15 |
|
LWH111-2.2-20 |
2.2 |
111 |
372 |
|
3 |
20 |
|
LWH108-2.5-15 |
2.5 |
108 |
413 |
5.5 |
2.5 |
15 |
|
LWH120-2.8-15 |
2.8 |
120 |
395 |
6.1 |
2.8 |
15 |
|
LWH120-3.2-15 |
3.2 |
120 |
437 |
6.1 |
3.3 |
15 |
|
LWH140-4.0-15 |
4.0 |
140 |
420 |
7.1 |
4.2 |
15 |
|
LWS140-4.0-15 |
4.0 |
140 |
460 |
7.1 |
3.8 |
15 |
|
LWH152-4.4-20 |
4.4 |
152 |
420 |
|
6.5 |
20 |
|
LWH140-5.0-15 |
5.0 |
140 |
500 |
7.1 |
4.9 |
15 |
|
LWH140-5.0-20 |
5.0 |
140 |
525 |
|
6.3 |
20 |
|
LWH152-5.0-20 |
5.0 |
152 |
460 |
|
7 |
20 |
|
LWH140-6.0-15 |
6.0 |
140 |
580 |
7.1 |
5.6 |
15 |
|
LWH152-7.0-20 |
7.0 |
152 |
610 |
|
8.6 |
20 |
|
LWH140-8.0-15 |
8.0 |
140 |
741 |
7.1 |
7.2 |
15 |
|
LWH140-10-20 |
10.0 |
140 |
965 |
|
11.4 |
20 |
|
LWH159-10.0-15 |
10.0 |
159 |
730 |
8 |
8.8 |
15 |
|
LWH180-10.0-15 |
10.0 |
180 |
605 |
9.1 |
10.1 |
15 |
|
LWH184-11-20 |
11.0 |
184 |
662 |
|
14.2 |
20 |
|
LWH184-12-20 |
12.0 |
184 |
710 |
|
15.4 |
20 |
|
LWH203-12-15 |
12.0 |
203 |
567 |
10.3 |
11.8 |
15 |
|
LWH204-12-20 |
12.0 |
204 |
610 |
|
16.5 |
20 |
|
LWH203-13.4-15 |
13.4 |
203 |
637 |
10.3 |
14.8 |
15 |
|
LWH204-15-20 |
15.0 |
204 |
735 |
|
18.7 |
20 |
|
LWH203-20-15 |
20.0 |
203 |
873 |
10.3 |
17 |
15 |
|
LWH204-20-20 |
20.0 |
204 |
940 |
|
23.4 |
20 |
|
LWH232-30-15 |
30.0 |
232 |
1020 |
12.6 |
28 |
15 |
|
LWH232-40-15 |
40.0 |
232 |
1315 |
12.6 |
34 |
15 |
|
LWH232-50-15 |
50.0 |
232 |
1590 |
12.6 |
39 |
15 |
The liner of breathing apparatus cylinders are made by high
strength aluminum 6061, thus the weight is 70%
lighter than conventional steel cylinders.
Advanced construction and producing technology
provide long working duration and high safety
factor. Cylinders can be made to many safety
standards all over the word, such as DOT, EN,
HSE, etc. They have a wide application in the
fields of firefighting, medical and mine
industry.
|
Specifications Model |
Volume
Lts/Cu ft |
Diameter
（mm/in)
|
Overall Length
（mm/in) |
Empty Weight
（Kg) |
Service Pressures（MPA) |
|
FQC84-0.6-30 |
0.6 |
84 |
193 |
0.5 |
30 |
|
FQC93-0.7-30 |
0.7 |
93 |
203 |
0.7 |
30 |
|
FQC85-1.0-30 |
1.0 |
85 |
292 |
0.8 |
30 |
|
FQC100-1.1-20 |
1.1 |
100 |
231 |
1 |
20 |
|
FQC103-1.1-30 |
1.1 |
103 |
234 |
1.2 |
30 |
|
FQC117-1.5-30 |
1.5 |
117 |
249 |
1.3 |
30 |
|
FQC112-1.6-30 |
1.6 |
112 |
268 |
1.2 |
30 |
|
FQC116-1.8-30 |
1.8 |
116 |
292 |
1.5 |
30 |
|
FQC96-2.0-30 |
2.0 |
96 |
433 |
1.5 |
30 |
|
FQC128-2.4-20 |
2.4 |
128 |
305 |
1.7 |
20 |
|
FQC114-3.0-30 |
3.0 |
114 |
446 |
2.1 |
30 |
|
FQC137-4.7-30 |
4.7 |
137 |
492 |
3 |
30 |
|
FQC157-6.0-30 |
6.0 |
157 |
470 |
3.6 |
30 |
|
FQC157-6.8-30 |
6.8 |
157 |
528 |
4.1 |
30 |
|
FQC175-9.0-30 |
9.0 |
175 |
560 |
5.2 |
30 |
Aluminum cylinder’s interior surface turns
cleaner after passivation treatment. Comparing
with steel cylinders, it has advantages of
lightweight and smelless. They are ideal for
storage of oxygen and other gases for medical
and rescue use. SHINEQUIP supplies two types of
O2 cylinders for your choice:
All aluminum Cylinders
|
Specifications Model |
Volume
Lts/Cu ft |
Diameter
（mm/in)
|
Overall Length
（mm/in) |
Empty Weight
（Kg) |
Service Pressures（MPA) |
|
LWH66-0.2-20 |
0.2 |
66 |
133 |
4.4 |
20 |
|
LWH66-0.28-20 |
0.2 |
66 |
164 |
4.4 |
20 |
|
LWH89-0.5-15 |
0.5 |
89 |
167 |
4.5 |
15 |
|
LWH75-0.7-15 |
0.7 |
75 |
295 |
4 |
15 |
|
LWH82-0.7-15 |
0.7 |
82 |
235 |
4.2 |
15 |
|
LWH89-0.7-15 |
0.7 |
89 |
207 |
4.5 |
15 |
|
LWH108-0.7-15 |
0.7 |
108 |
169 |
5.5 |
15 |
|
LWH89-1.0-15 |
1 |
89 |
269 |
4.5 |
15 |
|
LWH108-1.0-15 |
1 |
108 |
210 |
5.5 |
15 |
|
LWH89-1.4-15 |
1.4 |
89 |
345 |
4.5 |
15 |
|
LWH108-1.4-15 |
1.4 |
108 |
264 |
5.5 |
15 |
|
LWH108-2.0-15 |
2 |
108 |
346 |
5.5 |
15 |
|
LWH108-2.5-15 |
2.5 |
108 |
413 |
5.5 |
15 |
|
LWH140-4.0-15 |
4 |
140 |
420 |
7.1 |
15 |
|
LWH140-5.0-15 |
5 |
140 |
500 |
7.1 |
15 |
|
LWH140-6.0-15 |
6 |
140 |
580 |
7.1 |
15 |
|
LWH140-8.0-15 |
8 |
140 |
741 |
7.1 |
15 |
|
LWH159-10.0-15 |
10 |
159 |
730 |
8 |
15 |
|
LWH180-10.0-15 |
10 |
180 |
605 |
9.1 |
15 |
|
LWH203-12-15 |
12 |
203 |
567 |
10.3 |
15 |
|
LWH203-20-15 |
20 |
203 |
873 |
10.3 |
15 |
|
LWH232-30-15 |
30 |
232 |
1020 |
12.6 |
15 |
|
LWH232-40-15 |
40 |
232 |
1315 |
12.6 |
15 |
Full Carbon Wrap Cylinder
|
Specifications Model |
Volume
Lts/Cu ft |
Diameter
（mm/in)
|
Overall Length
（mm/in) |
Empty Weight
（Kg) |
Service Pressures（Mpa/psi) |
|
FQC85-1.0-30 |
1 |
85 |
292 |
0.8 |
30 |
|
FQC112-1.6-30 |
1.6 |
112 |
268 |
1.2 |
30 |
|
FQC96-2.0-30 |
2 |
96 |
433 |
1.5 |
30 |
|
FQC128-2.4-20 |
2.4 |
128 |
305 |
1.7 |
20 |
|
FQC114-3.0-30 |
3 |
114 |
446 |
2.1 |
30 |
|
FQC137-4.7-30 |
4.7 |
137 |
492 |
3 |
30 |
|
FQC157-6.0-30 |
6 |
157 |
470 |
3.6 |
30 |
|
FQC157-6.8-30 |
6.8 |
157 |
528 |
4.1 |
30 |
|
FQC175-9.0-30 |
9 |
175 |
560 |
5.2 |
30 |
seamless
steel gas cylinder
Shinequip
is the professional exporter of various types of
high pressure gas cylinder. The plant capable of
produce large, medium, small sizes high pressure
seamless cylinders. The cylinder scope range
from 8-35Mpa in working pressure, 0.4-120L in
water liter. We are able to supply high pressure
seamless steel cylinder, welded cylinder,
composite cylinder; Vehicle used CNG composite
cylinder, accumulator shells, welded insulated
cylinder, paintball cylinder, aluminum liner
fully wrapped with carbon fiber composite
cylinder in 680 sizes. Our products serve a wide
application in chemical industries, fire
fighting, petroleum industries, shipping,
energy, city construction, food process,
metallurgy, mechanics and electronic industry.
The plants have three kinds of international
quality system approvals (ISO9001:p2000, VDA6.1,
QS9000). And it also acquires more than twenty
kinds of international production approval
including the American DOT approval, Germany TUV
certification and Canada TC approval.
GB11640(GB5099) Standard Gas Cylinder
|
Type |
Outside Diameter Do.(mm) |
Water Capacity V(I) |
Height
(without valve) L(mm) |
Weight
(without valve cap)W(kg) |
Service pressure (MPA) |
Design Wall Thickness S(mm) |
Material |
|
WZA279-68-15 |
279 |
68 |
1410 |
76 |
15 |
6.0 |
34Mn2V |
|
WZA279-70-15 |
70 |
1450 |
78 |
|
WZA279-80-15 |
80 |
1640 |
90 |
|
WZA267-60-15 |
267 |
60 |
1360 |
67 |
5.8 |
|
WGA267-68-15 |
68 |
1520 |
76 |
|
WZA267-70-15 |
70 |
1560 |
78 |
|
WZA232-40-15 |
232 |
40 |
1200 |
48 |
5.0 |
|
WGA232-46.7-15 |
46.7 |
1385 |
54 |
|
WGA232-50-15 |
50 |
1475 |
57 |
|
WGA232-40-20 |
40 |
1230 |
56 |
20 |
6.3 |
|
WGA232-45-20 |
45 |
1370 |
62 |
|
WGA232-50-20 |
50 |
1500 |
68 |
|
WGA232-40-15 |
40 |
1200 |
48 |
15 |
5.0 |
30CrMo |
|
WGA232-46.7-15 |
46.7 |
1385 |
54 |
|
WGA232-50-15 |
50 |
1475 |
57 |
|
WGA232-40-20 |
40 |
1230 |
56 |
20 |
6.3 |
|
WGA232-45-20 |
45 |
1370 |
62 |
|
WGA232-50-20 |
50 |
1500 |
68 |
|
Type |
Outside Diameter Do.(mm) |
Water Capacity V(I) |
Height
(without valve) L(mm) |
Weight
(without valve cap)W(kg) |
Service pressure (MPA) |
Design Wall Thickness S(mm) |
Material |
|
WZA229-40-15 |
229 |
40 |
1250 |
48 |
15 |
5.0 |
34Mn2V |
|
WZA229-46.7-15 |
46.7 |
1390 |
54 |
|
WZA229-50-15 |
50 |
1440 |
57 |
|
WZA229-40-20 |
40 |
1250 |
56 |
20 |
|
WZA229-45-20 |
45 |
1420 |
62 |
6.3 |
|
WZA229-50-20 |
50 |
1540 |
68 |
30CrMo |
|
WGA229-40-20 |
40 |
1250 |
56 |
30CrMo |
|
WGA229-45-20 |
45 |
1420 |
62 |
30CrMo |
|
WGA229-50-20 |
50 |
1540 |
68 |
34Mn2V |
|
WMA219-36-15 |
219 |
36 |
1240 |
49 |
15 |
5.7 |
34Mn2V
37Mn |
|
WMA219-38-15 |
38 |
1300 |
51 |
|
WMA219-40-15 |
40 |
1520 |
59 |
|
WMA219-45-15 |
45 |
1520 |
59 |
|
WZA219-36-15 |
36 |
1240 |
44 |
4.8 |
34Mn2V |
|
WZA219-38-15 |
38 |
1300 |
47 |
|
WZA219-40-15 |
40 |
1360 |
50 |
|
WZA219-45-15 |
45 |
1520 |
55 |
|
WGA204-20-20 |
204 |
20 |
815 |
30 |
20 |
5.1 |
34CrMo4 |
|
WMA152-8-15 |
152 |
8 |
605 |
12.4 |
15 |
4.0 |
37Mn |
|
WMA152-9-15 |
9 |
665 |
13.4 |
|
WZA152-10-15 |
10 |
730 |
14.4 |
|
WMA152-12-15 |
12 |
855 |
16 |
|
WMA140-3.4-15 |
140 |
3.4 |
340 |
6.5 |
15 |
3.6 |
37Mn |
|
WMA140-4.0-15 |
4.0 |
390 |
7.3 |
|
WMA140-5.0-15 |
5.0 |
460 |
8.3 |
|
WMA140-6.0-15 |
6.0 |
530 |
9.4 |
|
WMA140-7.0-15 |
7.0 |
600 |
10.5 |
|
WMA140-8.0-15 |
8.0 |
690 |
12 |
|
WMA140-9.015 |
9.0 |
770 |
13 |
|
WMA140-10.0-15 |
10.0 |
840 |
14 |
|
WMA108-2.0-15 |
2.0 |
315 |
3.1 |
|
WMA108-2.3-15 |
2.3 |
350 |
3.4 |
|
WMA108-3.0-15 |
3.0 |
430 |
4.1 |
|
WMA108-3.4-15 |
3.4 |
485 |
4.5 |
|
WMA108-4.0-15 |
4.0 |
550 |
5.0 |
|
WMA108-4.4-15 |
4.4 |
595 |
5.4 |
|
WMA108-5.0-15 |
5.0 |
675 |
5.8 |
1、
We can supply the cylinders of different
pressure, water capacity according to the
requirements of customers.
2、
We can also supply the cylinders for
export according to the foreign customer’s
requirements of size , surface color and valve
of gas cylinders.
DOT-3AA Standard Gas Cylinder
|
Type |
Outside Diameter in.(mm) |
Water Capacity cu.in.(I) |
Height
in.(mm) |
Weight
lbs.(kg) |
Service pressure
(psi) |
Test pressure
(psi) |
Design
Wall Thickness in.(mm) |
Material |
|
8CF |
3.65″(90)
4.25″(108) |
109-115
(1.78-1.88) |
15.51″
(394) |
5.3-5.9
(2.4-2.7) |
1800 |
3000 |
0.097″(2.4) |
30CrMo
(4130×) |
|
10CF |
122(2.0) |
|
.3-5.9
(2.4-2.7) |
|
15CF |
183(3.0) |
12.4″(315) |
6.8(3.1) |
|
23CF |
268(4.4) |
16.9″(430) |
9.0(4.1) |
|
24CF |
283(4.64) |
23.4″(595) |
11.9(5.4) |
2015 |
3360 |
|
25CF |
287(4.7) |
25.2″(640) |
11.9(5.4) |
|
19CF |
207(3.4) |
25.2″(640) |
13.2 (6.0) |
2100 |
3500 |
0.102″(2.6) |
|
16CF |
207(3.4) |
|
|
|
15CF |
5.24″(133) |
183(3.0) |
10.37″
(263.5) |
5.3-6.2
(2.4-2.8) |
2175 |
3625 |
|
Type |
Outside Diameter in.(mm) |
Water Capacity cu.in.(I) |
Height
in.(mm) |
Weight
lbs.(kg) |
Service pressure
(psi) |
Test pressure
(psi) |
Design
Wall Thickness in.(mm) |
Material |
|
18CF |
5.24″
(133) |
207(3.4) |
19.1″(485) |
9.9(4.5) |
1800 |
3000 |
0.098″(2.5) |
30CrMo
(4130×) |
|
19CF |
220(3.6) |
14.0″(355) |
12.3(5.6) |
|
23CF |
275(4.5) |
12.8″(320) |
11(5.0) |
0.118″(3.0) |
|
26CF |
305(5.0) |
14.0″(355) |
12.3(5.6) |
|
20CF |
220(3.6) |
14.4″(365) |
10.6-12.8
(4.8-5.8) |
|
28CF |
305(5.0) |
17.5″(445) |
15(6.8) |
|
31CF |
409(6.7) |
19.3″(490) |
16.5(7.5) |
|
49CF |
635(40.4) |
14.6″(370) |
10.6-12.8
(4.8-5.8) |
|
33CF |
5.73″
(171)
7″
(178) |
428(7.0) |
19.3″(490) |
16.5(7.5) |
0.157″(4.0) |
30CrMo
(4130×) |
|
48CF |
635(10.4) |
17.3″(440) |
28.4(12) |
|
63CF |
816(13.4) |
24.4″(620) |
35.2(16) |
30CrMo
(4130×) |
|
37CF |
428(7.0) |
16.54″
(420) |
26.4(12) |
|
40CF |
476(7.8) |
22.44″ (570) |
34(15.5) |
30CrMo
(4130×) |
|
55CF |
635(10.4) |
27.76″ (706) |
40.7(18.5) |
|
55CF |
660(10.8) |
16.54″ (420) |
26.4(12) |
2015 |
3360 |
30CrMo
(4130×) |
|
70CF |
816(13.4) |
17.7″
(450) |
24.9-28.2
(11.3-12) |
|
80CF |
958(15.7) |
22.44″
(570) |
34(15.5) |
|
110CF |
1320(21.65) |
23.2″
(590) |
31.7-34.8
(14.4-15.8) |
30CrMo
(4130×) |
|
115CF |
1281(21) |
27.76″
(705) |
40.7(18.5) |
